Installation Requirements
|
Branda A7Plus |
Parameter |
|
Minimum installation size (Length*Width*Height) |
8200mm*3500mm*3100mm |
|
Pump room size |
2000mm*2000mm*1800mm |
|
Packing size |
4200mm*1400mm*1400mm |
|
Minimum equipment room size |
4 Square |
|
Power requirements |
380V 50Hz 18Kw |
|
Total equipment weight |
<2000kg |
|
Air Switch |
≥D100A, >30mA |
|
Water Inlet |
Pipe DN25, Flow>80L/min |
|
Air Pump |
≥0.7MPa,50L |
Parameter
|
Branda A7 Plus |
Parameter |
|
Total power |
15KW |
|
Fan motor power |
4 pcs 3Kw blowers total 12Kw |
|
Shampoo/Foam/Wax motor power |
0.37Kw |
|
Water consumption |
Standard wash 80L / car |
|
Electricity consumption |
Standard wash 0.4 kw h/car |
|
Wash liquid consumption (Foam/Shampoo/Wax) |
≈100ml/car |
|
Vehicle washing size |
5300mm*2000mm*2000mm |
|
Wax consumption |
≈15ml |
|
Full service wash time |
4.5Min/Car |
Branda A7 Plus Functions
|
Function |
A7 Plus |
|
Double Arm High Pressure Washing |
√ |
|
Chassis wash |
√ |
|
Shampoo Spray |
√ |
|
Bright Coating Wax |
√ |
|
Auto Air Dry |
√ |
|
Program Upgrade |
√ |
|
Hit Emergency Stop |
√ |
|
Shampoo Mixing System |
√ |
|
Phonetic Guiding System |
√ |
|
7 Inch Touch Panel |
√ |
|
Antifreeze System |
√ |
|
Quantity Calculation |
√ |
|
Fault Quote Query |
√ |
|
Self-help Guide Parking |
√ |
|
LED and Voice Prompt System |
√ |
|
